For Driver downloads please go directly to the FTDI Driver Page: FTDI VCP Driver Page. F.A.Q: Q: I have an older BMW with OBD2 Connector (16 pin) which uses K-Line - will this Interface work? A: Yes this interface will also work on older OBD2 BMW's using K-Line, however there is a cheaper option for you - please check our other auctions. /siemens-logo-8-software-download.html. USB connector plugs into most modern laptops! (USB 1.1 or 2.0) A Serial Port version was also available; click here for full specs. Compatible with all the latest cars which require a direct CAN connection for diagnostics. Fully backwards compatible with older cars using a single K-line or K plus L. Start K Manager software, and check the USB driver status on the bottom right of the KManager window. It should say 'Driver Installed'. It should say 'Driver Installed'. A second way to check the USB drivers are installed correctly is to open the Windows Device Manager and check the entry for the Hondata K-Series ECU does not have a yellow. K3FiiO-Born for Music. The XMOS USB receiver chip in the K3 directly converts any USB audio input to digital signals output via the coaxial and optical connectors, allowing you to connect to speaker systems, amplifiers, or other external decoders.

1. Usb K-line Interface Driver Download

CHIPSOFT J2534 Mid & K-line adapter is one of the most affordable adapters in its class. Support of various programs working via J2534 standard makes it an irreplaceable tool for diagnostics and chip tuning, and its price allows you to start your own business with minimum financial expenses. Various working modes of the adapter (J2534, K-Line adapter, CANHacker) substantially widen its functionality.

Technical specifications:

• modern powerful 32-bit ARM processor 72 MHz;
• work under the control of the real-time operational system (RTOS);
• support of the bus USB 2.0 Full-speed;
• update of the adapter firmware via USB;
• support of J2534 standard, partial support of J2534-2 standard;
• protection from polarity reversal, static stress;
• dual power to provide safe work (+5V USB socket, +12V/+24V OBD2 socket);
• support of power 24V to work with trucks and buses;
• set programming voltage 5 — 20V with the step 0.1 V onto pins 8, 9, 11, 12, 13 of the OBD2 socket, maximum current is equal to 20 mA;
• support of Single wire CAN bus (SW CAN);
• support of the second CAN BUS on pins 3 — 11 of the OBD2 socket (can be also crossed to pins 1 — 8, 12 — 13 via soldering bridges on the OBD2 plate inside the adapter);
• indication of the operating mode via 3 LEDs;
• OBD2 case;
• Mini USB socket to connect to the computer.

Support of the following protocols:

• ISO 11898 (raw CAN) up to 1Mb/s;
• ISO 15765-4 (CAN);
• ISO 14230-4 (Keyword Protocol 2000);
• ISO 9141-2;
• GM UART;
• SW CAN.

The adapter pinout

• 1 — SW CAN;
• 3 — CAN Hi (second CAN BUS);
• 4, 5 — Ground;
• 6 — CAN Hi (main CAN BUS);
• 7 — KLine (GM UART, ISO 9141-2, ISO 14230-4);
• 8 — can be used for setting voltage 5 — 20V;
• 9 — can be used for setting voltage 5 — 20V;
• 11 — CAN Lo (second CAN BUS), can be used for setting voltage 5 — 20V;
• 12 — can be used for setting voltage 5 — 20V;
• 13 — can be used for setting voltage 5 — 20V;
• 14 — CAN Lo (main CAN BUS);
• 15 — LLine (can also be short to the ground);
• 16 — +12V (in order to measure the voltage in the OBD socket and adapter power backup).

The adapter is a universal device able to work in various modes:

• J2534 compatible device;
• K-Line adapter;
• CANHacker.

The adapter supports the protocol ISO22900 and works with Tech2Win. Initially the device works as a J2534 compatible device. You can change the device mode using the shortcuts located in Start- Programs - CHIPSOFT J2534 Mid:

• Make J2534;
• Make K-Line;
• Make CANHacker.

VAG-K+CAN Commander 1.4 Installation Guide

Usb K-line Interface Driver Download

VAG K+CAN Commander is obd2repair diagnostic interface for vag group. VAG K+CAN Commander Full Diagnostic via CAN-und Special-Function via K-Line. Do you know how to install VAG-K+CAN Commander 1.4?

VAG K+CAN Commander 1.4 VAG K+CAN 1.4 Commander
Here OBD2Repair share with you VAG K+CAN Commander Full VAG-K+CAN Commander 1.4 Installation Guide.
1. Driver installation
1.1. Donlgle Driver -> in folder 'Dongle Driver USB' start file 'inf_inst.exe'
1.2. Interface USB driver -> in folder 'Interface Driver USB/Executable' start file 'CDM_Setup.exe'
2. Software installation
place folder 'VAG-K+CAN Commander' at usful for you place
3. Connect USB dongle to your PC
4. Connect interface to your PC
5. If your operation system is Windows XP - skip this step
Check proper setting of the USB-COM port
Your interface is detected from Windows like COM port (USB-COM).
You must check whether setting of CURRENT port are proper.
From 'My Computer->properies->hardware->device manager->Ports (COM&LPT)->USB Serial Port (COM x)'
select properties (right mouse button) then 'Port Settings->Advanced'. Your value for 'Latency Timer (msec) should be 1!
If not set to 1. You can have a look in the file 'advanced settings usb-com port.bmp' how seems settings.
NOTE: Next time when you connection your interface to another USB port settings above must be repeated so recommended is fisrst time when you starting usage to set proper setting of for all possible USB ports.
In the next SW releases need from setting of ports will be skiped.
6. Starting SW
You can start 'VAG-K+CAN Commander.EXE' file from folder mentioned in step 2. above.
Now your VAG K+CAN Commander is ready for use.
